Technical Features and Functions |
Functions of Control Unit |
|
Dimensions: (LxHxW): 545 x 107 x 100 |
-
Automatic
-
Door stand open
-
One way traffic
-
Two was traffic
-
Night lock
-
Manual open by hand and closing by spring
-
Push & Go (automatic opening by pushing)
-
Synchronisation of two operators
-
Cyclic opening and closing
|
|
Weight
of operation: 12kg |
-
Drive for one door
-
Maximum Opening 95°
-
Power Requirements: 230 VAC / 50hz;
-
IP22 protection
-
Opening Time Adjustment: 0-20 s;
-
Separate Inputs for motion detectors, presence
sensors and photocells
-
DC
Output: for Auxiliary sensors and electric lock
-
Power failure - doors close by spring
|
|
Adjustments (via control unit or digital selector) |
|
 |
-
Regulation of opening and closing speeds
-
Regualtion of acceleration and deceleration's
-
Safety sensor inhibiting distance in opening
mode
-
Pushing thrust limitation
-
Pause time(0-20s)
-
Wind stop force intensity
-
Push and go activation distance
-
Intensity of final thrust on closing phase to
ensure electric lock is latched
-
Release time of 0.5 seconds for lock before
opening of door
|
-
You can have a right or left opening door, push
or pull opening, speed and power opening mode:
for every mode of the assembly the same operator
can be used.
-
Activation of the functions can be selected via
the on board 3 way switch on the lateral side of
the operator, manual key switch or via a digital
selector.
-
Programming the functions and parameters can be
done by the on board dip switch or via the
digital function selector
-
The regulation of the opening angle (maximum
95°) must be adjusted at the initial
installation of the operator
-
In
a power fail situation it can be opened by hand
and closed by spring
|
